Vigilex VD-HV
Explosion Vent Panel
Single domed high vacuum resistant - Vacuum resistance : 500 mbar
APPLICATIONS
The VIGILEX VD-HV is a strong domed panel, designed for use in applications where the operating pressure approaches the burst pressure, or where high vacuum pressure may exist.
In the need for applications where the explosion vent is exposed to pulsating duty such as reverse jet cleaning systems on dust collectors with high vacuum.
With a large flange and gasket included, the one layer domed panel VIGILEX VD-HV meets all your safety issue to protect equipment and facilities. The standard burst pressure is 0.1 bar (max. 0.5 bar) at 22 °C (72 °F).
Design : single domed sst 304 L
Fully frame black EPDM gasket (-40°+80°C)
Integrated stainless steel flange
Panel material stainless steel 316L
Fully frame white silicone FDA gasket and 1935/2004 CE (-60°+200°C)
High temperature graphite gasket (-200°+500°C)
Integrated stainless steel 316L flange
Ex II GD
EN 14 491
EN 14 994
EN 14 797
EN 1127.1
EU Certificate : INERIS 15ATEX0001X
Production quality assurance notification : INERIS 08ATEXQ406
Preguntas sobre el dimensionamiento de los paneles de explosión para silo-filtro
1 file(s) 222.90 KB
Questions relatives au dimensionnement des panneaux d'explosion pour les silos-filtres
1 file(s) 222.90 KB
- 1
- 2
Fully frame black EPDM gasket (-40°+80°C)
Explosion vent panel dimensions
| INTERNAL DIMENSION (mm) | INTERNAL DIMENSION (Inches) | EXTERNAL DIMENSION (mm) | AREA (cm2) | DOWNLOAD PDF |
|---|---|---|---|---|
| DIMENSIONS INTÉRIEURES (mm) | DIMENSIONS INTÉRIEURES (Inches) | DIMENSIONS EXTÉRIEURES (mm) | SURFACE (cm2) | TÉLÉCHARGER LE PDF |
| MEDIDAS INTERIORES (mm) | MEDIDAS INTERIORES (Inches) | MEDIDAS EXTERIORES (mm) | SUPERFICIE (cm2) | DESCARGAR PDF |
| INNENMAßE (mm) | INNENMAßE (Zoll) | AUßENMAßE (mm) | FLÄCHE (cm2) | DOWNLOAD PDF |
| ВНУТРЕННИЙ РАЗМЕР (мм) | ВНУТРЕННИЙ РАЗМЕР (дюймы) | ВНЕШНИЙ РАЗМЕР (мм) | ПЛОЩАДЬ (см²) | ЗАГРУЗКА PDF |
| 150 x 600 | 6 x 24 | 230 x 680 | 885 | |
| 170 x 470 | 7 x 19 | 250 x 550 | 785 | |
| 220 x 420 | 9 x 17 | 300 x 500 | 910 | |
| 229 x 229 | 9 x 9 | 310 x 310 | 515 | |
| 229 x 305 | 9 x 12 | 310 x 386 | 690 | |
| 247 x 610 | 10 x 24 | 327 x 690 | 1485 | |
| 270 x 458 | 11 x 18 | 350 x 538 | 1220 | |
| 300 x 500 | 12 x 20 | 380 x 580 | 1480 | |
| 305 x 457 | 12 x 18 | 386 x 538 | 1385 | |
| 305 x 610 | 12 x 24 | 386 x 690 | 1845 | |
| 340 x 385 | 13 x 15 | 404 x 449 | 1250 | |
| 340 x 440 | 13 x 17 | 404 x 504 | 1430 | |
| 350 x 650 | 14 x 26 | 430 x 730 | 2255 | |
| 375 x 655 | 15 x 25 | 460 x 740 | 2445 | |
| 410 x 410 | 16 x 16 | 480 x 480 | 1660 |
| INTERNAL DIMENSION (mm) | INTERNAL DIMENSION (Inches) | EXTERNAL DIMENSION (mm) | AREA (cm2) | DOWNLOAD PDF |
|---|---|---|---|---|
| DIMENSIONS INTÉRIEURES (mm) | DIMENSIONS INTÉRIEURES (Inches) | DIMENSIONS EXTÉRIEURES (mm) | SURFACE (cm2) | TÉLÉCHARGER LE PDF |
| MEDIDAS INTERIORES (mm) | MEDIDAS INTERIORES (Inches) | MEDIDAS EXTERIORES (mm) | SUPERFICIE (cm2) | DESCARGAR PDF |
| INNENMAßE (mm) | INNENMAßE (Zoll) | AUßENMAßE (mm) | FLÄCHE (cm2) | DOWNLOAD PDF |
| ВНУТРЕННИЙ РАЗМЕР (мм) | ВНУТРЕННИЙ РАЗМЕР (дюймы) | ВНЕШНИЙ РАЗМЕР (мм) | ПЛОЩАДЬ (см²) | ЗАГРУЗКА PDF |
| 457 x 890 | 20 x 28 | 537 x 970 | 4040 | |
| 470 x 610 | 18 x 24 | 550 x 690 | 2845 | |
| 490 x 490 | 19 x 19 | 570 x 570 | 2380 | |
| 490 x 590 | 19 x 23 | 570 x 670 | 2865 | |
| 525 x 668 | 21 x 26 | 630 x 765 | 3400 | |
| 586 x 920 | 23 x 36 | 666 x 1000 | 5360 | |
| 610 x 610 | 24 x 24 | 690 x 690 | 3695 | |
| 653 x 653 | 26 x 26 | 740 x 740 | 4260 |
Other sizes available
| INTERNAL DIMENSION (mm) | INTERNAL DIMENSION (Inches) | EXTERNAL DIMENSION (mm) | AREA (cm2) | DOWNLOAD PDF |
|---|---|---|---|---|
| DIMENSIONS INTÉRIEURES (mm) | DIMENSIONS INTÉRIEURES (Inches) | DIMENSIONS EXTÉRIEURES (mm) | SURFACE (cm2) | TÉLÉCHARGER LE PDF |
| MEDIDAS INTERIORES (mm) | MEDIDAS INTERIORES (Inches) | MEDIDAS EXTERIORES (mm) | SUPERFICIE (cm2) | DESCARGAR PDF |
| INNENMAßE (mm) | INNENMAßE (Zoll) | AUßENMAßE (mm) | FLÄCHE (cm2) | DOWNLOAD PDF |
| ВНУТРЕННИЙ РАЗМЕР (мм) | ВНУТРЕННИЙ РАЗМЕР (дюймы) | ВНЕШНИЙ РАЗМЕР (мм) | ПЛОЩАДЬ (см²) | ЗАГРУЗКА PDF |
| Ø 200 | 8 | Ø 268 | 310 | PDF |
| Ø 250 | 10 | Ø 341 | 480 | PDF |
| Ø 300 | 12 | Ø 390 | 695 | PDF |
| Ø 350 | 14 | Ø 424 | 930 | PDF |
| Ø 400 | 16 | Ø 473 | 1230 | PDF |
| Ø 450 | 18 | Ø 545 | 1580 | PDF |
| Ø 500 | 20 | Ø 574 | 1935 | PDF |
| INTERNAL DIMENSION (mm) | INTERNAL DIMENSION (Inches) | EXTERNAL DIMENSION (mm) | AREA (cm2) | DOWNLOAD PDF |
|---|---|---|---|---|
| DIMENSIONS INTÉRIEURES (mm) | DIMENSIONS INTÉRIEURES (Inches) | DIMENSIONS EXTÉRIEURES (mm) | SURFACE (cm2) | TÉLÉCHARGER LE PDF |
| MEDIDAS INTERIORES (mm) | MEDIDAS INTERIORES (Inches) | MEDIDAS EXTERIORES (mm) | SUPERFICIE (cm2) | DESCARGAR PDF |
| INNENMAßE (mm) | INNENMAßE (Zoll) | AUßENMAßE (mm) | FLÄCHE (cm2) | DOWNLOAD PDF |
| ВНУТРЕННИЙ РАЗМЕР (мм) | ВНУТРЕННИЙ РАЗМЕР (дюймы) | ВНЕШНИЙ РАЗМЕР (мм) | ПЛОЩАДЬ (см²) | ЗАГРУЗКА PDF |
| Ø 600 | 24 | Ø 676 | 2790 | PDF |
| Ø 700 | 28 | Ø 790 | 3830 | PDF |
| Ø 750 | 30 | Ø 842 | 4400 | PDF |
| Ø 800 | 31 | Ø 880 | 5000 | PDF |
| Ø 900 | 36 | Ø 980 | 6280 | PDF |
| Ø 980 | 39 | Ø 1070 | 7510 | PDF |
Other sizes available
| STIF MODEL | DESIGN | Pstat @ 22 °C | EFFICIENCY RATIO | MAX VACUUM | KST MAX |
|---|---|---|---|---|---|
| MODÈLE STIF | CONCEPTION | Pstat @ 22 °C | COEFFICIENT D’EFFICACITÉ | RÉSISTANCE À LA DÉPRESSION MAX | KST MAX |
| MODELO STIF | DISEÑO | Pstat @ 22 °C | RADIO DE EFICIENCIA | VACÍO MÁXIMO | KST MAX |
| STIF MODELL | DESIGN | Pstat @ 22 °C | WIRKUNGSGRAD | MAX. VAKUUM | KST MAX |
| МОДЕЛЬ STIF | ДИЗАЙН | PSTAT ПРИ 22°C | КОЭФФИЦИНТ ЭФФЕКТИВНОСТИ | МАКСИМАЛЬНОЕ ДАВЛЕНИЕ | KST MAX |
| VD-HV | Single domed Integrated frame | 100 ≤ Pstat ≤ 500 (±15%) - Pstat ≤ 100 (±20%) | 80 % - 100 % | 200 - 600 mbar | 500 bar.m/s |
